Air FilterStandard Briggs & Stratton Air Cleaner
Anti Scalp Wheels2 Standard
ArmrestsOptional
Bagger Capacity4.9 bushels
Blade Design0.164 in. / 0.417 cm Steel with Blade Stiffner
Blade Tip Speed17,860 ft/min / 5,444 m/min
Box Dimensions82.0 in. x 49.0 in. x 35.0 in. / 208.3 cm x 124.5 cm x 88.9 cm
CARB CompliantNot CARB Compliant
Caster Tires11 in. x4 in. - 5 in. Pneumatic
ClutchElectromagnetic
Cooling SystemAir Cooled
Crankshaft1" (25 mm) w/Steel Protector
Cup HolderStandard
Cutter SystemSteel Cutting Blade
Deck Design10-Gauge steel IrongForged®
Deck Material10 Gauge Steel
Deck Size42 in / 107 cm
Discharge ChuteSide
Drive SystemHYDRO
Drive Tires18 in. x 7.5 in. - 8 in (45.7 cm x 19.1 cm - 20.3 cm)
Drive TypeRear-Wheel Drive
Engine22 hp Briggs and Stratton EXI 724cc
Engine BrandBriggs and Stratton
Engine Displacement (cc)724 cc
Engine Horsepower22.0 hp
Engine Power (kW)16.4 kW
Foot Operated Height of CutOptional
Forward Ground/Transport SpeedUp to 7.0 mph / 11.2 kph
Forward Mowing SpeedUp to 7.0 mph / 11.2 kph
Fuel Capacity - 3 gal. / 11.4 L / 12 Qt.
Fuel Type - Gasoline
Greasable Bearings - Yes
Height of Cut - 1.5 - 4.5 in. / 3.8 - 11.4 cm
Hitch Bracket - Standard
Hour Meter - Optional
Hydraulic Dampeners - Yes, Non-Cavitating
Hydraulic Drive - Standard
Number of Blades - 2
Product Type - TimeCutter
Product Use - Residential
Recommended Oil Type - 10W-30
Roll-Over Protection System - (ROPS)Optional
Seat. - 16" Handcrafted
Spindle Bearings - Maintenance-free
Spindle HousingCast - Aluminum
Start Type - Electric
Steering Controls - Dual Wrap Around Levers
Steering Dampeners - Standard Dampers
Terrain Type - Flat with Obstacles
Tow Capacity - Combined machine, user, towed weight may not exceed 1,000 lbs.
Transmission - Dual Hydrostatic HG-EZT2100
Washout Port - Standard
Weight - 527 lbs / 239 kg
